XP95 Open-Area VID - White Body (Red Flash) - Isolating

Name: XP95 Open-Area VID - White Body (Red Flash) - Isolating
Brand: Discovery
SKU: 55000-010APO

55000-010APO

The XP95 Open-Area VID has been developed for use in situations where there is a risk that sounders will not be heard.

Technical specification

General	Warranty 10 year
Mechanical	Colour White Materials housing Polycarbonate Product depth 97.5mm Product diameter 104mm Weight 205g Product depth 3.84in Product diameter 4.09in
Electrical	Polarity L1 & L2 are polarity sensitive Power-up surge current 1.2mA Maximum power-up time <1 second Quiescent current 333μA Quiescent current tested at 24V dc Supply voltage (max) 28V dc Supply voltage (min) 17V dc Supply voltage (Vmin-Vmax) 17 to 28V dc
Environmental	Humidity (max) 95% RH Humidity (min) 0% RH Humidity Note no condensation or icing Humidity 0% to 95% (no condensation or icing) Operating temperature (max) 55°C Operating temperature (min) -10°C Operating temperature -10 to 55°C IP rating Value IP65 Operating temperature 14 to 131°F Operating temperature (max) 131°F Operating temperature (min) 14°F
